6KW Hybrid Solar System With 10KWh Wall Solar Battery
System Type: 6KW 10KWh Hybrid Single phase
Battery: 10.24KWh lifepo4 powerwall battery
Output Voltage: 230VAC ± 5% @50/60Hz
Certificate: CE/TUV/CSA/CEC/UL/ISO
Lead Time:7-10 days
Payment: T/T, Credit Card, Paypal, Western Union
Place of origin: China
Description
6KW Hybrid solar panel system with a 10kwh lifepo4 battery can be used for residential, small commercial, and industries. The solar system generates the electricity to power the home load, and the power can be stored in the lifepo4 energy storage battery, extra electricity can be sold to the local utility grid.
Technical Data
- DATA
| 6KW Hybrid Solar Power System Components | ||||
| Item | Name | Description | Quantity | Warranty |
| 1 | Solar Panel | PERC 550w Mono | 10 pcs | 25 years |
| 2 | Inverter | 6kw Hybrid solar inverter | 1 set | 5 years |
| 3 | PV Combiner Box | customized according to the solar system | 1 set | 5 years |
| 4 | Battery | 10kwh Powerwall lifepo4 battery | 1 set | 5 years |
| 5 | Solar Mounting Structure | Roof/Ground Install(Customized) | 1 set | 10 years |
| 6 | PV Cable | 4 mm2 DC PV Cable | 100m | 10 years |
| 7 | MC4 | MC4 Connector | 12pcs | – |
| 8 | Standard Wooded Package + System Connecting Drawings (Easy Installing) | |||
| 9 | System Capacity could be adjustable according to the customer’s situation | |||
Components
Mono-crystalline Solar panel
Mono-crystalline PERC Solar panel
* 144 mono solar panel cells;
* 182mm mono PERC type;
* Power 550W 560W 570W 580W available;
* Maximum efficiency to 21.29%;
* Brand panel available: Longi/JA/Jinko/Trina
Hybrid Solar Inverter
6KW On grid and off grid solar inverter
* Pure sine wave, high frequency
* Smart Battery Management
* LCD colored touch screen display
* Over load/ short circuit protection
* Max 16 pcs parallel for hybrid operation
10KWh LifePO4 Battery
10kwh powerwall lifePO4 battery
* Over 6000 cycle times and high energy density
* The built in BMS ensures high safety and stability.
* Easy installation and space-saving.
* The ingress protection rate is IP20(IP65 optional).
Mounting Structure for Solar Panel
Our ground solar mounting structures are all aluminum steel materials. They are designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs.
Solar System Accessories
* Combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to tell us.
