Growatt SPF 6000 ES Plus Off Grid Single Phase Inverter
Model Number: Growatt SPF 6000 ES Plus
Output Voltage:230VAC 50/60Hz
Output power: 6kw
Inverter: High frequency Pure sine wave AC output
Parallel Capacity: up to 6 units in parallel
Warranty: 2 years
Fast Shipping: from the warehouse in Germany
Place of Origin: China
Description
The Growatt SPF 6000 ES Plus series inverter is the off grid solar inverter single phase low voltage type 48VDC. It has 2 MPPT trackers, a max PV array power of up to 8000W. It supports connecting in parallel, the parallel capacity of up to 6 units maximum. This Growatt off grid inverter has less noise during working compared to growatt 5000 ES series, and has a good reputation among end users. It is suitable for residential power supply, commercial, and small industries.
Two MPPT Trackers:
With two MPPTs, the off grid inverter can be connected to two different sets of solar panels. This is especially useful when the solar panels are installed in different orientations or are subject to different shading patterns, allowing these two solar arrays to work independently to achieve premium output.
Two AC input terminals with integrated transfer switch:
This design enables Growatt SPF 6000 ES Plus inverters to be compatible with different types or sources of AC power. For some remote areas or places with complex off-grid environments, there may be multiple available AC power options, such as AC power provided by small diesel generators and occasionally accessible external mains power. The two AC input terminals can flexibly deal with these different AC power situations.
Technical Data
- Output Data
- Solar Charger
- Physical Data
| Model | SPF 6000 ES Plus |
| Battery Voltage | 48VDC |
| Battery Type | Lithium/Lead-acid |
| Inverter Output | |
| Rated Power | 6000VA/6000W |
| Parallel Capability | Yes, 6 units maximum |
| AC Voltage Regulation (Battery Mode) |
230VAC ± 5% @ 50/60Hz |
| Surge Power | 12000VA |
| Efficiency (Peak) | 93% |
| Waveform | Pure sine wave |
| Transfer Time | 10ms typical，20ms Max |
| Model | SPF 6000 ES Plus |
| Solar Charger | |
| Maximum PV Array Power | 8000W |
| MPPT Range @ Operating Voltage | 120VDC ~ 450VDC |
| Number of Independent MPP Trackers/ Strings Per MPP Tracker |
2/1 |
| Max. input current per MPP tracker | 16A |
| Maximum PV Array Open | 500VDC |
| Circuit Voltage | |
| Maximum Solar Charge Current | 100A |
| AC Charger | |
| Charge Current | 80A |
| AC Input Voltage | 230VAC |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) |
| Frequency Range | 50Hz/60Hz (Auto sensing) |
| Model | SPF 6000 ES Plus |
| Physical | |
| Protection Degree | IP20 |
| Dimension (W/H/D) | 460/395/132mm |
| Net Weight (kgs) | 13.5 |
| Operating Environment | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Altitude | <2000m |
| Operating Temperature | 0°C- 55°C |
| Storage Temperature | -15°C-60°C |
Growatt SPF 6000 ES Plus Details
Off Grid Inverter
- Plug-and-Play terminal for PV port
- Dual MPPT trackers
- Maximum PV input voltage up to 500VDC
- Configurable grid or solar input priority
- Parallel for scalability
- Dust-proof filter for harsh environment
- Two AC input terminals with integrated
- Support Wifi and GPRS remote monitoring
- For batteries: Lithium/Lead acid/Gel
From Grid or Solar
In off-grid systems, users can decide whether to give priority to grid power or solar panel power according to the actual situation. For example, during periods when solar resources are abundant, such as at noon on sunny days, users can set solar input as the priority. In this way, the system will give priority to using the electrical energy generated by solar panels to meet the load demand and use grid power as a backup, thereby making the best use of clean energy,then reduce the cost of obtaining power from the grid. For some scenarios such as hospitals, which require a stable power input, if solar power generation is unstable, then the grid input can be set as the priority, and at the same time, the solar panel with a battery backup system can be used as a supplementary energy source.
