JA N-type Bifacial Double Glass 590-615W Solar Panel
MOQ: One pallet of 36 pieces
Model: JA JAM66D45
Cell: Mono-16BB
Power Range:590-615W
Glass: JA solar double glass
Certification: CE, TUV, CQC, BIS
Lead Time:7-10 days
Payment: T/T, Credit Card, Paypal, Western Union
Warranty: 30 Years
Ja Solar DatasheetDescription
As the official authorized agent of JA solar panels, HBOWA provides you with JA solar panels for all models of grade A type with competitive prices. The string of numbers on the back of each solar panel is the barcode of the product, you can check and identify it on the authenticity page of the JA official website. The warranty of each panel is 25 to 30 years. Our MOQ is one pallet and we provide comprehensive after-sales service, feel free to reach out.
- Mechanical Parameters
- Operating Parameters
| Cell | Mono-16BB |
| Junction Box | IP68, 3 diodes |
| Output Cable | Portrait:300mm(+)/400mm(-); Landscape:1500mm(+)/1500mm(-) |
| Cable Cross Section Size | 4mm2(IEC), 12 AWG(UL) |
| No. of cells | 132(6*22) |
| Weight | 33.1kg |
| Dimension | 2382±2mmx1134±2mmx30±1mm |
| OperationalTemperature | -40°C~+85°C |
| Maximum System Voltage | DC 1500V |
| Maximum Series Fuse Rating | 35A |
| Nominal Operating Cell Temperature | 45±2°C |
| Fire Performance | UL Type 29 |
JA N-Type Solar Panel
Assembled with 16BB N-Type cells and half-cell configuration, these solar modules offer the advantages of higher power generation better LCOE, better temperature coefficient, n-type with very lower LID, as well as better low irradiance response.
Delivery
Each solar panel will be packaged well into the wood pallet box. We support door-to-door delivery service, taking care of custom clearness for you. Before, during, and after shipment, we will closely track the status of the goods and give you feedback as soon as possible. Just sit back and relax while we handle these for you.
