15kw Solar System With Battery Backup
System Type: 15KW 28.67KWh Off Grid Single phase
Inverter: Growatt, Solis brand available
Battery: 14.34KWh lifepo4 lithium battery * 2
Output Voltage: 230VAC ± 5% @50/60Hz
MOQ: 1 piece, fast delivery from China
Description
Composition:
HBOWA 15kw solar system consists of 27 pieces of 550W solar panels, three 5kw solar inverters in parallel, the 51.2V 280Ah lithium battery with 2 pieces in parallel as battery storage, and other solar accessories. The complete off grid solar system is the most popular of our off grid type solar system series.
Durable and Reliable Solar System:
HBOWA 15kw solar system is an efficient system that absorbs the sunlight to produce green energy for end users, the components of the system are durable and reliable, HBOWA offers solar system certificates such as CE, TUV, CSA, CEC, UL, ISO, etc to ensure the high quality.
Features:
- Lithium ion phosphate battery cells with high energy density and low resistance;
- Battery with the long life cycle of over 6000 cycle times and a long lifespan of 10 years;
- Fast battery charging and discharging rate;
- Communication protocol: CAN and RS485 to support the battery and inverter connection;
- Battery management system and control system for overload, over current, over voltage, etc;
- Modular design, standardized production, easy installation;
- Reliable electricity power supply from green solar energy.
Application:
– Electrification of rural or urban residences
– Power supply for telecommunication equipment
– Public and residential lighting systems
-Emergency standby power
– Security and surveillance
– Lighting and signaling systems
– Isolated residences and isolated communities
Technical Data
- DATA
Model | 3KW-Off | 5KW-Off | 10KW-Off | 15KW-Off | 20KW-Off |
Mono-facial solar panel 550W/41.95V |
6 pieces | 10 pieces | 18 pieces | 27 pieces | 36 pieces |
Growatt Inverter | 3000es * 1 | 5000es * 1 | 5000es * 2 | 5000es * 3 | 5000es * 4 |
DC Combiner Box | Customized According to Solar System Configuration | ||||
Energy Storage Battery | Lithium Ion Battery |
28.67KWh Lithium Ion Battery | Lithium Ion Battery |
||
PV Cable 4 mm2 | 100 meter | 100 meter | 200 meter | 200 meter | 400 meter |
Mounting Brackets | 1 set | ||||
MC4 Connector | 8 pieces | 12 pieces | 20 pieces | 30 pieces | 40 pieces |
Components
Solar Panel
Maximum Power(Pmax): 550W
Maximum Power Voltage: 41.95V
Maximum Power Current: 13.11A
Maximum Efficiency: 21.29%
Dimension: 2278*1134*30mm
Weight: 26.4kg Total number: 27 pieces
Brand panel available: Longi/JA/Jinko/Trina
Off Grid Solar Inverter
In the 15kw solar power system, we use three 5kw off grid inverters in parallel, the inverter offers several advantages, including an equalization charging function that helps to extend battery life and maintain optimal performance. It also features configurable grid or solar input priority, allowing users to prioritize their power sources based on availability and preference. Additionally, the inverter supports optional WiFi/GPRS remote monitoring, enabling users to monitor and control their system from a distance.
Floor Standing LifePO4 Battery
The LiFePO4 phosphate lithium batteries floor standing type have a high energy density and a lifespan of 10 years, exceeding 6000 cycles, IP20 ingress protection rate, we also have IP65 floor mounted type batteries to meet the market demands.
Aluminum Mounting Bracket
Our solar mounting structure of the 15kwh solar system offers a robust and versatile solution for 15 kilowatt solar system installations. It is designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs.
Solar System Accessories
* 3 in and 1 out, combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to contact us.
Application Show (8)
Related Product (11)
In this 15kw solar power system, we use 27 pieces of 550w solar panels. Other powers of the solar panels are available. Considering the total power of the system is 15kw, the power of the solar panels you choose, and the solar inverter specifications, then you will know about the number of solar panels.
The number of batteries in the 15kw solar power system you need depends on the specification of the batteries and the total electricity energy you need at night or on rainy days. For example, if you need 20 KWH to use at night, and you have no connection to the utility grid, and you consider the 51.2V 200Ah battery, then the battery number would be: 20KWH/51.2V/200Ah = 2 pieces.
Sure. Installation of the 15kw solar power system will increase the value of your house. It is a valuable investment for you to reduce electricity bills, make your electricity energy independently, and increase the property in the long run.
The 15 kW solar system will generate about 59.4kwh power per day considering there are 4 hours of effective sunshine in your area, suitable for 5 to 8 people in a family. It can power home appliances such as refrigerators, lights, ovens, air conditioners, electronic lights, etc.
We provide professional services for the 15 kilowatt solar system through WhatsApp/email/WeChat, assisting you with installation and answering any questions you may have. For each solar system we sell, we have photos and installation demo videos, you can find them on our Youtube channel. Our engineer will also go overseas to help you if necessary.
You can also consult local solar installers. They all offer free home solar installation consultations and cost evaluations. We suggest that you get installation quotations from at least three companies to compare prices and be sure to inquire about any discounts and preferential activities they may offer.
It depends on your installation location, your local sunlight conditions, your local feed in tariff, your usual electricity cost, the approximate value of your electricity consumption, and your total cost of the 15kw solar power system fee and the installation fee.
You need to calculate the total value of electricity that the solar energy system can generate annually. Then, divide the total cost of purchasing and installing the system by this total value to figure out the payback period.
