3KW Off Grid Solar System 5KWH Powerwall Battery

CheckSystem Type: 3KW 5KWh Off Grid Single phase

CheckInverter Brand: Growatt, MUST

CheckBattery: 51.2V 100Ah 5KWh wall mount lifepo4 battery

CheckOutput Voltage: 230VAC ± 5% @50/60Hz

CheckCertificate: CE/TUV/CSA/CEC/UL/ISO

CheckLead Time:7-10 days

CheckPayment: T/T, Credit Card, Paypal, Western Union

Description

3kw off grid solar system with 5kwh rack mount battery3kw off grid solar kit low voltage with 5kwh powerwall battery

How does a 3KW off grid solar system work?

The solar panels of the 3KW off-grid solar system will generate DC electricity by absorbing energy from the sun, the off grid inverter than convert the DC into AC and supply the load through AC cable, the extra electricity will be stored in the wall mounted lifepo4 battery for later use during night or rainy days when there is no sun.

How many kilowatt-hours of electricity can this solar energy system produce?

It depends on where you install the solar panel system as different places will get different energy from the sun. For example, if we have 4 hours of efficient sunlight each day, then we multiply the total power of the solar panels by 4 hours to get the total electricity: 550W*6*4 = 13200Watt hour = 13.2KWH. per day.

How do I install the 3KW off grid solar system?

We have technical support and comprehensive after sales services for you by whatsapp, wechat, and email. We have operation instruction videos on our YouTube channel, we will send installation video to you when you buy these goods. Of course, you can find the solar system installer in your local places, they will help to check your place and the installation direction of the solar panels for you, make sure to choose more than three installers to compare the price and services before making your informed decision.

Components

550W solar panel
Solar Panel

Mono-crystalline Solar panel

Mono-crystalline PERC Solar panel

Maximum Power(Pmax): 550W

Maximum Power Voltage: 41.95V

Maximum Power Current: 13.11A

Open Circuit Voltage: 49.90V

Short Circuit Current: 14.09A

Maximum Efficiency: 21.29%

Dimension: 2278*1134*30mm

Weight: 26.4kg  Total number: 6 pieces

Brand panel available: Longi/JA/Jinko/Trina

3KW Inverter

Off grid Solar System Inverter

We support you brand  Growatt off grid inverters and MUST off-grid inverters in the market with favorable prices. The inverters are all high frequency pure sine wave inverters which have built-in MPPT solar charge controller, and are compatible with HBOWA lifepo4 batteries.They can be connected in parallel for more power needs. For more details, feel free to contact us.

3kw off grid system inverter - MUST or Growatt
Residential Energy Storage Solution-HBOWA Wall mounted battery
Battery Pack

Powerwall Battery

The powerwall lifepo4 battery has high energy density and long lifespan, over 6000 cycle times. It is lightweight,  easy to install, equipped with smart BMS protection system to ensure the high safety and stability of the lithium iron phosphate battery.

Mounting Structure

Mounting Structure for Solar Panel

Our ground solar mounting structures are all aluminum steels which offer a robust and versatile solution for solar system installations. It is designed to withstand various environmental conditions, ensuring long-term stability and durability.

solar mounting structure
PV Accessories(combiner box MC4 connector PV Cable)
Accessories

Solar System Accessories

* Combiner box with voltage resistance of 500V;

* PV single core cable 4m㎡,6m㎡,10m㎡ etc;

* MC4 connectors, according to solar panels.

If you need any other accessories, feel free to tell us.

What can HBOWA support you?

As the configuration of the 3KW off grid solar system will be different according to your detailed requirements, so feel free to send an inquiry to us for your customized solar system project!

3KW 5KWh off grid solar system
