40kw Solar System With Batteries
System Type: 40KW Off grid Single phase
Inverter Brand: OEM
Battery: 10KWh lithium battery * 4
Output Voltage: 230VAC ± 5% @50/60Hz
Environmental friendly clean energy
Suitable for residential, commercial, and industries.
MOQ: 1 piece, fast delivery from China
Description
High Quality Solar Products
HBOWA 40KW solar system consists of the PERC mono-facial 550W PV modules with a warranty of 25 years, the pure sine wave high frequency solar inverters with a warranty of 5 years, and high energy density rack mount lifepo4 batteries 5KWh with a warranty of 5 to 10 years, and other solar accessories. HBOWA has automatic production lines and a strict quality control standard to ensure your premium solar power systems.
Independent Green Energy
The 40KW solar system is equipped with 40KWh lifepo4 storage batteries. When the solar panels generate green electricity, and supply your home appliances loads, the excessive power can be stored in these lifepo4 batteries. Then the batteries provide you with an uninterrupted and stable electricity power supply in emergency scenarios.
Support Connecting To Utility Grid
The solar inverter of this 40 kw solar system is the hybrid inverter, which also has the function of connecting to the utility grid. You can feed the excessive electricity to the utility grid if your local policies allow you to do so.
Applications for 40KW Solar System
- Commercial Buildings: commercial offices and building can install the 40kw solar system to reduce power costs, the solar system can provide backup power for the whole building when the grid is not available;
- Industrial Areas: For powering equipment, the 40kw solar system can help the industrial park reduce the electricity cost and work as backup power during grid failures;
- Farming: The 40kw solar system can power irrigation systems, crop processing machinery, and cold storage facilities on remote farms during sunny and cloudy days.
- Healthcare: 40kw solar systems ensure reliable green energy for hospitals, clinics, rural healthcare centers, and laboratories when there is no electricity from grid.
- Telecommunications: The 40kw solar system can power remote telecommunication towers and maintain a consistent energy supply, ensuring 24/7 operation.
- Public Infrastructure: The solar system 40kw with battery 40kwh can support community centers, government offices, and other essential services power supply, with battery storage for nighttime and emergency use.
Technical Data
- 40 kw Solar System
| 40kw Solar System Components | ||||
| Item | Name | Description | Quantity | Warranty |
| 1 | Solar Panel | PERC 550w Mono | 72 pcs | 25 years |
| 2 | Solar Hybrid Inverter | 10kw | 4 set | 5 years |
| 3 | PV Combiner Box | customized | 1 pc | 5 years |
| 4 | Battery | 10.24KWh rack mounted battery |
4pcs | 5-10 years |
| 5 | Solar Mounting Structure | Roof/Ground Install (Customized) |
1 set | 10 years |
| 6 | PV Cable | 4 mm2 DC PV Cable | 200m | 10 years |
| 7 | MC4 | MC4 Connector | 20pcs | – |
| 8 | Standard Wooded Package + System Connecting Drawings (Easy Installing) | |||
| 9 | System Capacity could be adjustable according to customer’s situation | |||
Components
Solar PV Modules
Maximum Power(Pmax): 550W
Open Circuit Voltage: 49.90V
Short Circuit Current: 14.09A
Maximum Efficiency: 21.29%
Dimension: 2278*1134*30mm
Weight: 26.4kg Total number: 36 pieces
Brand panel available: Longi/JA/Jinko/Trina
Off grid Solar Inverter
Off Grid Hybrid Inverter 10KW * 4
Inverter Power: 10kW
Output Voltage: L/N/PE 220V 230 VAC
Max Efficiency: 97.6%
Monitoring mode: WIFl, APP
Protection Degree:lP65
Warranty:5 years
Solar Modular Mounting Structure
Our ground solar mounting system offers a robust and versatile solution for solar system installations. It is designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs.
Solar System Accessories
* Combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to tell us.
Related Product (11)
The cost of the 40ky solar system depends on various factors, such as solar panels brand, quantity of the solar panels, solar inverters, solar batteries, and installation complexity. This 40kw solar system with 40kwh battery EXW costs about $21500, it is advisable to contact our sales team for an accurate quotation based on your specific conditions and requirements.
It depends on the power of the solar panels and solar inverters you choose. In this 40kw solar system, we set the 40kw hybrid solar inverter, and the power of the solar panels is 550 watt, the number of the solar panels is:
40KW / 550 watt = 72 pieces.
The 40kw solar system with batteries consists of 72 pieces of 550w solar panels, four 10kw hybrid solar inverters, 40kwh lithium ion phosphate batteries, and other accessories. If the solar panels get 4 hours of effective sunlight per day, they will generate 550*72/1000*4 = 158.4 KWH electricity power per day for your house loads.
The installation of the 40kw solar system is easy for those who have basic electrical knowledge. We also have an operation guide for each of our solar products, you can view them in our video channel. Besides, if you need help, our technician team will give professional guides by remote video connection and will go to your place to provide guides if necessary.
As the number of 550 watt solar panels is 72 pieces, and each space of the solar panels is 2278mm * 1134mm = 2.76 square meters, the space needed for the whole solar system would be at least:
2.76 * 72 = 198.72 square meters.
