6KW 10KWh Off Grid Solar System Split Phase
System Type: 6KW 10KWh Off Grid split phase
Inverter Brand: Growatt
Battery: 10KWh rack lifepo4 battery
Output Voltage:104-110-115-120V(50Hz/60Hz +/-0.3 Hz)
Certificate: CE/TUV/CSA/CEC/UL/ISO
Lead Time:7-10 days
Payment: T/T, Credit Card, Paypal, Western Union
Description
6KW Split Phase Off Grid Solar System With 10KWH Lifepo4 Battery:
The 6kw off grid solar system generates about 23.4kwh electricity considering there are 4 hours of effective sunshine per day. This is the split phase off grid solar system which is suitable for application areas in America, Canada, Japan, Panama, Cuba, Mexico, Ecuador, El Salvador, etc. The solar system includes 10kwh lifepo4 battery which can store the electricity for later use at night or rainy days.
Does it support selling electricity back to the grid with this system?
No, this is the off grid solar system which gain electricity generated from the sun and supplies the load independently, it does not support connecting to the grid, suitable for houses in rural areas and those without electricity, islands, communication databases, boats, etc.
What is the solar mounting structure included?
In this off-grid solar system, roof mounting components with aluminum materials are included, and ground mounting systems are also available if you prefer installing the solar system on flat ground.
What HBOWA Offer:
We not only produce our brand HBOWA solar panels, and lifepo4 lithium batteries, but also provide other Tie1 solar panels, such as Jinko, JA, Longi, Canidian, and Trina solar panels, solar inverters such as Growatt, Deye, Solis, MUST, etc. For solar panels, inverters, and lithium batteries, OEM and ODM services are available, feel free to reach out.
Components
Mono-crystalline panel
Maximum Power(Pmax): 585W
Maximum Power Voltage: 42.52V
Maximum Power Current: 13.76A
Open Circuit Voltage: 51.16V
Short Circuit Current: 14.55A
Maximum Efficiency: 22.65%
Dimension: 2278*1134*30mm
Weight: 31.8kg Total number: 10 pieces
6KW Growatt Inverter
- Low frequency-inverter 120/240Vac Split Phase output.
- Integrated MPPT charge controller
- Optional WIFI/ GPRS remote monitoring.
- Built-in pure copper low-frequency transformer
- Configurable grid or solar input priority
Grade A LifePO4 Battery
In this off-grid solar power system, we use 51.2V 200Ah lifepo4 lithium battery server rack type. We choose grade A prismatic battery cells, it has over 6000 cycle times, and the built-in BMS protection board ensures the high safety and stability of the lifepo4 battery. The warranty of the battery is 5 years, 10 years are optional.
Mounting Structure for Solar Panel
Our ground solar mounting system offers a robust and versatile solution for solar system installations. It is designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs.
Solar System Accessories
* 3 in and 1 out, combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to tell us.
What can HBOWA support you?
As the configuration of the 6KW split phase off grid solar system will be different according to your detailed requirements, so feel free to send an inquiry to us for your customized solar system project!
