Solar Panel Support Mounting Structure
Tile Angel: 5-45 angle
Wind Load: 60m/s
Snow Load: 1.4KN/m2
Color: Silver or customized
Applicable solar module: framed or frameless
Hook: highly customized according to roof details
Warranty: 10 Years
Tile Roof StructureDescription
Solar panel support mounting structures are used to strengthen the positioning of the solar panels on the roof and flat plants. They ensure the optimal angle of the solar panels to receive the sunlight, thus improve the energy efficiency of the solar panels. Solar panels are usually large and heavy, the solar panel support structures can bear the weight and withstand the external forces such as snow, wind, and hail.
We support solar panel mounting structures for metal sheet roofs, tile roofs, flat roofs, and even pole mounted brackets for specific applications. Each component of the support mounting structure has been optimized with better design, and better support for an easier, faster installation experience. The rail structure has high strength with less material utilization and cost, and the anti-sliding design is better for solar panel positioning stability.
Advantages
Solar Panel Mounting Structure
● Suitable for various roofs of residential and commercial uses.
● Flexible configuration for solar system mounting components.
● Save money on installation time and cost.
● No need to install the slide rail, save the site installation time and cost.
● Compatible with different types of solar modules.
● Compatible with framed / unframed components.
Structure Assembly
Every detail of the rail structure design of the solar panel support mounting structure has been optimized in terms of structural properties for better strength with less material utilization and cost.
