10000 Watt Off Grid Solar System
System Type: 10KW 20KWh Off Grid Single phase
Inverter: 5.5KW single phase * 2
Battery: 5.12KWh powerwall battery * 4
Output Voltage: 230VAC ± 5% @50/60Hz
OEM & ODM: support
Certificate: CE/TUV/CSA/CEC/ISO
Place of origin: China
Description
Solar Panels:
In this 10000 watt off grid solar power system, we select 550W PERC mono-facial solar panels for you, if you need TOPCon and bifacial solar panels, please let us know in advance, we have strong business partnerships with Tier 1 solar panel manufacturers such as Jinko, JA, Trina, Longi, and so on, also support OEM services to support you, if you want to step into solar power business with your brand.
Off Grid Inverter:
The off grid inverter is our GTS series single phase low voltage type, that support solar energy storage, utility grid energy charging the storage battery, and 220V AC sine wave output. The optimal hardware and software protection features can display fault types for easy troubleshooting, you can connect your phone to view the status of the 10 kw off grid solar system.
LifePO4 Wall Mounted Battery:
The lifepo4 battery in this 10kw off-grid solar system has high energy density and a long cycle life of over 6000 times, the wall-mounted lifepo4 battery has a smart BMS protection system, ensuring safety and high performance. It is designed with the concept of easy installation, easily expanded to the capacity that meets your needs. In this 10000 watt off grid solar system, we use 4 pieces of 5KWh wall mounted lifepo4 batteries in parallel, the capacity is up to 20Kwh. We also support customization, if you need other types of batteries like lead acid batteries, or other types of lithium batteries, feel free to tell us in advance.
How to install a 10kw off grid solar system?
HBOWA provides after sales services on WhatsApp/WeChat/Email, assisting with installation and answering any questions you may have, you can reach us 24 hours on work days. For solar systems we sell, we have photos and installation demo videos for you, you can check that on our Youtube channel too. Our engineer will also go overseas to help you if necessary.
You can also consult local solar installers. They all offer free home solar installation consultations and cost evaluations. We suggest that you get installation quotations from at least three companies to compare prices and be sure to inquire about any discounts and preferential activities they may offer.
Safe Delivery:
We collaborate with reliable carriers to provide trackable delivery and offer insurance against theft, loss, and damage. Of course, if you have a preferred freight forwarder, we can also arrange shipments on an EXW (Ex Works) basis.
Technical Data
- 10KW Off Grid Solution
- Inverter Data
| 10kw Off grid Solar System Components | ||||
| Item | Name | Description | Quantity | Warranty |
| 1 | Solar Panel | PERC 550w Mono | 18pcs | 25 years |
| 2 | Off grid Inverter | 5.5kw | 2 set | 3 years |
| 3 | PV Combiner Box | 5 Inputs 1 output | 1 pc | 5 years |
| 4 | Battery | 5.12KWh powerwall battery |
4pcs | 5-10 years |
| 5 | Solar Mounting Structure | Roof/Ground Install (Customized) |
1 set | 10 years |
| 6 | PV Cable | 4 mm2 DC PV Cable | 200m | 10 years |
| 7 | MC4 | MC4 Connector | 20pcs | – |
| 8 | Standard Wooded Package + System Connecting Drawings (Easy Installing) | |||
| 9 | System Capacity could be adjustable according to customer’s situation | |||
| Rated output power (W) | 5500 |
| Rated AC Output | 230 Vac(200-240 Vac),50/60Hz |
| Output Voltage Waveform | Pure Sine Wave |
| Rated Battery Voltage | 48Vdc |
| Max.MPPT Charging Current | 100A |
| MPPT Quantity | 1 |
| MPPT Voltage Range | 120-450Vdc |
| Weight (kg) | 12 |
| Waterproof level | IP20 |
| Dimensions | 350*130*455mm |
| Warranty | 3 Years |
Components
Mono-crystalline panel
| Cell Type | 182x91mm Perc |
| Number of Cells | 144cells(2×72) |
| Dimensions | 2278x1134x30mm |
| Weight | 26.4KG |
| Maximum Power (Pmax) | 550Wp |
| Maximum Power Voltage (Vmp) | 41.95 |
| Module Efficiency STC (%) | 0.2129 |
| Brand | Longi/Jinko/JA/Trina/OEM |
| Warranty | 25 Years |
Off grid Solar System Inverter
Grade A LifePO4 Battery
| Nominal Energy | 5.12KWh 100Ah |
| MAX Charge/Discharge Current | 100A |
| Cycle Life | Over 6000 times |
| Cooling Way | air cooling |
| Waterproof level | IP20(IP54) |
| Operating Charge Temperature | 0℃ – 55℃(32℉ – 131℉) |
| BMS Protection | Over discharge, over current, short circuit protection, over temp,etc. |
| Net Weight | 44kg |
| Product Size | 410*592*160mm |
| Warranty | 5-10 years |
Mounting Structure for Solar Panel
Our ground solar mounting system offers a robust and versatile solution for solar system installations with aluminum and stainless steel materials. It is designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs. Warranty is 10 years for the mounting system.
Solar System Accessories
* 3 in and 1 out, combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to tell us.
